Combustion Equipment
Burners
ENCON Thermal Engineers
Burners
IIP-ENCON Film Burners (Saves : 5-15%)
- Winner of President’s award for Saving Fuel
- Designed and Developed by ENCON in collaboration with IIP & PCRA
- Useful for wide range of industrial applications
- Multi-fuel usage Burners & Combustion Equipments
IIP-ENCON Film Burners are available in the following sizes :
| Size | Firing Rate at 24″ wg | Firing Rate at 36″ wg |
|---|---|---|
| 2A | 3-20 ltrs/hr | 4-24 ltrs |
| 3A | 5-35 ltrs/hr | 7-40 ltrs |
| 4A | 10-65 ltrs/hr | 15-85 ltrs |
| 5A | 20-120 ltrs/hr | 25-150 ltrs |
| 6A | 30-180 ltrs/hr | 40-200 ltrs |
IIP-ENCON Gas Burners are available in the following sizes :
| Model | Capacity |
|---|---|
| 50 M3/hr Nozzle Mix Burner | 400,000 Kcal/hr |
| 100 M3/hr Nozzle Mix Burner | 800,000 Kcal/hr |
| 50 M3/hr Pre Mix Burner | 400,000 Kcal/hr |
| 100 M3/hr Prel Mix Burner | 800,000 Kcal/hr |
Gas Ring Burners
Developed by ENCON-Herrmann (Germany) at ENCON’s R & D Centre.
High Velocity Burners
Ideal for Non-ferrous Melting furnaces, Tundish pre heating, hotair generator.
| Burner size |
|---|
| ENCON HIGH VELOCITY – 3A |
| ENCON HIGH VELOCITY – 4A |
| ENCON HIGH VELOCITY – 5A |
Mono-Block Burners
We are importing & marketing Mono-Block Burners from Herrmann (Germany) and Olympia (Japan). Light Oil / Heavy Oil Burner is available in the following Size :
| Model | Fuel Rating Kg/h | Control | Motor Kw |
|---|---|---|---|
| HL 50B | 3.1 – 5.5 | ON/OFF | 435 VA |
| HL 120 B | 6 – 11.5 | ON/OFF | 515 Watts |
| HLZ 120 B | 6 – 11.5 | 2 Stage | 500 Watts |
| HLZ 250 B | 16 – 30 | 2 Stage | 575 Watts |
| HLZ 550 | 19 – 50 | 2 Stage | 650 Watts |
Herrmann HSD fired Burners are available in the following sizes :
| S. No. | Model | Firing Rate | Stage |
|---|---|---|---|
| 1 | HL 60 BL | 3.1 – 5.5 ltrs/hr | Single Stage |
| 2 | HL 120 BL | 6 – 12 ltrs/hr | Single Stage |
| 3 | HLZ 120 BL | 6 – 12 ltrs/hr | Two Stage |
OLYMPIA GAS BURNERS are available in the following sizes :
| Model | Capacity ( Max. Output ) |
|---|---|
| GOM – 1N | 100,000 KCal/Hr |
| GOM – 2N | 200,000 KCal/Hr |
| GOM – 3N | 300,000 KCal/Hr |
